Porsche 911 Carrera, Carrera S, Carrera 4, Carrera 4S (Type 933) Service Manual: 1995 - 1998
Engine covered in this Porsche repair manual:
- 1995: 3.6 liter (M64.07 and M64.08)
- 1996 - 1998: 3.6liter (M64.23 and M64.24)
Transmission:
- G50 (6-speed manual, RWD)
- G64 (6-speed manual, AWD)
- A50 (4-speed automatic)
This manual includes a complete engine disassembly and rebuilding guide, with full details on techniques and specifications, as well as camshaft and timing chain replacement techniques with engine in car.
Complete removal and disassembly guide, including clutch disassembly, clutch cable and linkage rebuilding, clutch hydraulics service.
Technical highlights:
- Full-color repair manual pages (black and white electrical section)
- In depth maintenance instructions for everything from changing the engine iol and Tiptronic transmission fluid to replacing the cabin microfilter.
- Type 993 enthusiast guide with year-to-year model specifics, and a comprehensive listing of Porsche option codes.
- Step by step engine/transmission assembly removal and installation.
- Illustrated engine teardown and rebuild, with camshaft and timing chain replacement, detailing wear limits and nominal values.
- Fuel injection and ignition system service and component testing of different Bosch DME engine management systems, including the secondary air injection (SAI) system.
- Clutch, flywheel and rear main seal service.
- Front and rear drivetrain service, including front (C4) and rear differential service.
- Brakes, steering, suspension and ABS maintenance, troubleshooting and repair for both vacuum boost (C2) and hydraulic-boost (C4) brake systems.
- Heating and air-conditioning repair, including A/C component replacement.
- Body adjustments and repair, including convertible top, sunroof and targa top service and adjustment.
- Electrical system service, with an easy-to-use illustrated component location section.
- Wiring schematics for selected models, with DME systems, power distribution, grounds, convertible top ad other hard-to-find circuits.
