$60 Core Charge & Free Return Shipping Included in Price: Core charge refunded when your old torque converter is received. A UPS return shipping call tag will be included in the box.

Shipping: 1 - 3 Day Delivery in USA (Please Select "AMERICA-ECONOMY" at Checkout)

DESCRIPTION & SPECS
Each RECON Certified torque converter is rebuilt to the highest-quality standards in the industry and warranted to be free from manufacturing defects in material and workmanship for 4-years, 100,000-miles from the date of purchase. Our unmatched 5-step remanufacturing process combines the precision of computers with the experience of engineers to ensure consistently high quality is achieved.

Torque Converter:

• Remanufactured, 10.75" Body Diameter, Flats/Flanged Hub Type
• 4 Mounts, Pads Mount Type, 9" Bolt Circle, No Ring Gear
• 447AB, 520AA, 520AB, 556AA, 556AB, 556AC Stamped Codes
• Low Stall, 22 Turbine Splines, Electronically Modulated Converter Clutch
• Grooved Clutch Friction Type, Lock-Up

NAME SPECS
Body Diameter Inches 10.75
Hub Type Flats/Flanged
Number of Mounts 4
Mount Type Pads
Bolt Circle Inches 9
With Ring Gear No
Codes Dye/Ink Stamped 447AB, 520AA, 520AB, 556AA, 556AB, 556AC
Pump Stall Low
Turbine Internal Spline Count 22
Lock-Up Unit Yes

TRANSMISSIONS
NAME YEARS
62TE 2007 - 2021
62TEA 2009 - 2016

VEHICLE FITMENT
YEARS VEHICLE DRIVE TYPES
2008 - 2016 Chrysler Town & Country FWD
2007 - 2010 Chrysler Sebring FWD, AWD
2007 - 2008 Chrysler Pacifica FWD, AWD
2011 - 2014 Chrysler 200 FWD
2009 - 2019 Dodge Journey FWD, AWD
2008 - 2020 Dodge Grand Caravan FWD
2008 - 2014 Dodge Avenger FWD, AWD
2014 - 2021 Ram ProMaster 3500 FWD
2014 - 2021 Ram ProMaster 2500 FWD
2014 - 2021 Ram ProMaster 1500 FWD
2012 - 2015 Ram C/V FWD
2009 - 2014 Volkswagen Routan FWD
