This new Clymer Harley Davidson title includes 736 pages, complete color wiring diagrams and over 100 pages of troubleshooting flow charts. as well as hundreds of illustrations and original photographs developed from the complete disassembly of the machine.

Every Clymer Manual contains hundreds of original photographs and illustrations developed from a complete disassembly and assembly of the Motorcycle. This, in addition to extensive research, allows Clymer to achieve an un-matched level of detail, accuracy & clarity.

The step-by-step instructions and two column text with large print are user friendly, bold figure numbers make it easy to quickly match instructions with illustrations and photos. Thumb tabbed chapters, numbered table of contents and extensive index make it possible to locate the desired section quickly. This manual includes a Quick Reference Data section with frequently used specifications.

Model Coverage: Softail FLS/FXS/FXC
Year Range: 2011 2012 2013 2014 2015 2016

• FLS 103 Softail Slim (2012-2016)
• FLSS 110 Softail Slim (2016)
• FLSTC Heritage Softail Classic (2011)
• FLSTC 103 Heritage Softail Classic (2012-2016)
• FLSTC ANV Heritage Softail Classic, 110th Anniversary Edition (2013)
• FLSTF Fat Boy (2011)
• FLSTF Fat Boy 103 (2012-2016)
• FLSTF Fat Boy Lo 103 (2012-2016)
• FLSTFB Fat Boy Lo (2011)
• FLSTFB ANV Fat Boy Lo, 110th Anniversary Edition (2013)
• FLSTFB 103 Fat Boy Lo (2012-2016)
• FLSTFB 103 ANV Fat Boy Lo, 110th Anniversary Edition (2013)
• FLSTFBS 110 Fat Boy Lo (2016)
• FLSTN Softail Deluxe (2011)
• FLSTN 103 Softail Deluxe (2012-2016)
• FLSTNSE CVO Softail Deluxe (2014)
• FLSTSB Softail Cross Bones (2011)
• FTSTSE2 CVO Softail Convertible (2011)
• FTSTSE3 CVO Softail Convertible (2012)
• FXCWC Rocker C (2011)
• FXS 103 Blackline (2012-2013)
• FXSB 103 Softail Breakout (2014-2016)
• FXSBSE 110 Softail Breakout (2013-2015)
• FXST 103 Softail Standard (2011-2013)

Table of Contents:

QUICK REFERENCE DATA
CHAPTER ONE / GENEREAL INFORMATION
CHAPTER TWO / TROUBLESHOOTING
CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP
CHAPTER FOUR / ENGINE TOP END AND EXHAUST SYSTEM
CHAPTER FIVE / ENGINE LOWER END
CHAPTER SIX / CLUTCH AND PRIMARY DRIVE
CHAPTER SEVEN / TRANSMISSION AND SHIFT MECHANISM (2006 MODELS)
CHAPTER EIGHT / TRANSMISSION AND SHIFT MECHANISM (2007-2009 MODELS)
CHAPTER NINE / AIR/FUEL AND EMISSIONS CONTROL SYSTEMS (CARBURETED MODELS)
CHAPTER TEN / AIR/FUEL AND EMISSIONS CONTROL SYSTEMS (EFI MODELS)
CHAPTER ELEVEN / ELECTRICAL SYSTEM
CHAPTER TWELVE / WHEELS, HUBS AND TIRES
CHAPTER ELEVEN / FRONT SUSPENSION AND STEERING (TELESCOPIC FORK MODELS)
CHAPTER THIRTEEN / FRONT SUSPENSION AND STEERING (SPRINGER FORK MODELS)
CHAPTER FOURTEEN / REAR SUSPENSION
CHAPTER FIFTEEN / BRAKES
CHAPTER SIXTEEN / BODY AND FRAME
INDEX
COLOR WIRING DIAGRAMS
