Clymer Repair Manual
This new Clymer Harley Davidson title includes 672 pages, complete color wiring diagrams as well as hundreds of illustrations and original photographs developed from the complete disassembly of the machine.
Clymer motorcycle repair manuals are written specifically for the do-it-yourself enthusiast. From basic maintenance to troubleshooting to complete overhaul, Clymer manuals provide the information you need. The most important tool in your tool box may be your Clymer manual
Models Covered:
FLHTC Electra Glide Classic (2010-2013)
FLHTCU Ultra Classic Electra Glide (2010-2013)
FLHTK Electra Glide Ultra Limited (2010-2013)
FLHR Road King (2010-2013)
FLHRC Road King Classic (2010-2013)
FLTRX Road Glide Custom (2010-2013)
FLTRU Road Glide Ultra (2011-2013)
FLHX Street Glide (2010-2013)
FLHTCUSE5 CVO Ultra Classic Electra Glide (2010)
FLHTCUSE6 CVO Ultra Classic Electra Glide (2011)
FLHTCUSE7 CVO Ultra Classic Electra Glide (2012
FLHTCUSE8 CVO Ultra Classic Electra Glide (2013)
FLHXSE CVO Street Glide (2010)
FLHXSE2 CVO Street Glide (2011)
FLHXSE3 CVO Street Glide (2012)
FLTRUSE CVO Road Glide Ultra (2011, 2013)
FLTRXSE CVO Road Glide Custom (2012)
FLTRXSE2 CVO Road Glide Custom (2013)
FLHRSE5 CVO Road King Custom (2013)
Table of Contents:
QUICK REFERENCE DATA
CHAPTER ONE / GENEREAL INFORMATION
CHAPTER TWO / TROUBLESHOOTING
CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP
CHAPTER FOUR / ENGINE TOP END AND EXHAUST SYSTEM
CHAPTER FIVE / ENGINE LOWER END
CHAPTER SIX / CLUTCH AND PRIMARY DRIVE
CHAPTER SEVEN / TRANSMISSION AND SHIFT MECHANISM (2006 MODELS)
CHAPTER EIGHT / TRANSMISSION AND SHIFT MECHANISM (2007-2009 MODELS)
CHAPTER NINE / AIR/FUEL AND EMISSIONS CONTROL SYSTEMS (CARBURETED MODELS)
CHAPTER TEN / AIR/FUEL AND EMISSIONS CONTROL SYSTEMS (EFI MODELS)
CHAPTER ELEVEN / ELECTRICAL SYSTEM
CHAPTER TWELVE / WHEELS, HUBS AND TIRES
CHAPTER ELEVEN / FRONT SUSPENSION AND STEERING (TELESCOPIC FORK MODELS)
CHAPTER THIRTEEN / FRONT SUSPENSION AND STEERING (SPRINGER FORK MODELS)
CHAPTER FOURTEEN / REAR SUSPENSION
CHAPTER FIFTEEN / BRAKES
CHAPTER SIXTEEN / BODY AND FRAME
INDEX
COLOR WIRING DIAGRAMS
